PLC – Siemens
Here at Technique Learning Solutions we offer single courses on the Siemens Range of PLC’s designed for experience courses or a total course designed around the PLC system with a certification gained at the end.
Please do not confuse us with cheap imitation courses, we offer first class PRACTICAL training using state of the art PLC systems and the latest software. These PLC’s have been carefully selected to match the latest current trends in industry, to match what industry is using. We DO NOT use simulator software, our training is very much hands on, allowing you the confidence when completing the course to work in the real world. You cannot gain this with simulators. Presently 90% of the industry run with either Allen Bradley or Siemens S7 PLC’s.. Why learn on something which isn’t used in the real world? Don’t get ridiculed in the real world, by having unusable theoretical skills. ALL our trainers are industry leaders, who are time served, experienced and highly qualified in the subject field, with a minimum of 20 years each in the industry. We can accommodate most makes of PLC’s, however, if you are new to the industry, we would HIGHLY recommend learning on the major players first using real PLC’s, real software and real training rigs.
We are the ONLY accredited centre to also offer industry recognised, City & Guilds qualifications in PLC, which is run in tandem to the EAL qualification. We are ISO 9001, ISO 14001 and OSHAS 18001 approved. This is testament to our ongoing investment and the quality of training we provide.
Please before you book a course, give us a call on 0800 112 3310, come and take a look around our superb centres or listen to what the industry says about us.
Essential Book supplied *throughout* course!
First exam fee included!
EAL Level 3: (Typically Siemens S7, Allen Bradley and Mitsubishi are covered)
We have an extensive range of PLC training courses available covering all PLC manufacturers and levels of expertise from the complete novice to the advanced. ALL of our training courses can be tailoured to your own requirements.
ALL our courses will be based on the relevant software and hardware. We aim to make ALL our courses as practical as possible, leading to ‘real world’ skills and not just theoretical skills.
No prior knowledge is required for this course as it starts from scratch and assumes no previous experience, you will reach the skilled level where you can look at becoming a programmer, get into engineering maintenance in an industrial environment, fault find or make amendments to programs, this is the course for you.
The ‘Typical’ 10 day level 3 course usually covers 2 or 3 of the major manufacturers, Siemens S7, Allen Bradley and Mitsubishi (This can be amended to other manufacturers if you have a particular requirement). The course aims to be 90% practical, as we believe the easiest way to learn is to do it! Every student works on their own dedicated training rig and computer, enabling you to get the most from the course. A full set of course notes and a USB drive full of other manuals is provided at the end of the course.
We can also cover a wide range of manufacturers including :
- Siemens Step 5 PLC Training (Using Step 5, Quadriga or Others)
- Allen Bradley PLC 3 & 5 Training (AB6200 Software)
- RSLogix 5 PLC Training
- SLC PLC Training (RSLogix 500)
- ControlLogix PLC Training (RS Logix5000)
- MicroLogix PLC Training (RSLogix 500)
- S7-200 PLC Training (Step 7 Micro)
- S7-300 PLC Training (Step 7 or TIA Portal)
- S7-400 PLC Training (Step 7 or TIA Portal)
- Kuhnke PLC Training (Kubes)
- Omron PLC Training (Syswin)
- Modicon PLC Training (ProWorx and Others)
- Mitsubishi PLC Training (Medoc, GX Developer, GPP & Others)
- Toshiba PLC Training
- GE Fanuc PLC Training
- GEM 80 PLC Training
- Telemecanique PLC Training
- Most other PLC manufacturer training undertaken.
We also cover a wide range of SCADA Systems to enable engineers to modify and add to existing screens, fault find through systems, set up communications etc.
To achieve certification, candidates must be able to:
- Demonstrate an Understanding of the Internal Architecture of PLCs, their Applications and Knowledge of the Number Systems they use.
- Demonstrate an Understanding of Typical Input and Output Devices used with PLCs, their Selection and how they are Interfaced to the PLC.
- Investigate and Display an Understanding of the Basic Programming Techniques used with PLCs.
- Produce a Correctly Developed Program for a PLC to Control a Specified Process and Document the Completed Program to a Satisfactory Standard.
- Demonstrate an Understanding of How to Monitor PLC Operation, Force Devices and Fault Find PLC Controlled Processes.
With ALL our courses we offer unbiased technical support and access to a wealth of knowledge and information upon completion. Once you’ve completed your course with Technique, you can be assured that our service doesn’t end there…
Our Tutors are qualified, highly experienced, enthusiastic, knowledgeable and extremely friendly, you can take full advantage of all the tips of the trade, personal experiences and practical advice they offer. This short theory course is intensive, but no compromise is made on the course content. The atmosphere is relaxed and enjoyable which creates a good learning environment.
Beginner Course Description:
This Siemens Beginner course aims to enable maintenance personnel to be able to understand the Programmable Logic Controller program, make minor modifications to the program and to fault find quickly using both software and printouts.
- Introduction to PLC Hardware
- Shortcut keys
- Format of Ladder Diagrams, CSF and Statement Lists
- Introduction to IEC 1131
- Use of Timers & Counters
- Connection of field devices
- Special Functions & Blocks
- Program uploading and downloading
- Addressing and Device Number Systems
- Commonly used instructions
- Diagnosing faults using forced addressing
- Configuration, Addressing & Performance Criteria of CPU’s
- Practical Exercises on Plant Simulation Systems.
Intermediate: Course Description
This Siemens Intermediate training course is aimed at personnel who already have some general experience of Programmable Logic Controllers but who wish to learn the idiosyncrasies of a specific model, or modify & expand existing programme codes.
- Networking protocols and configuration
- Programming Techniques
- Advanced Diagnostic Applications
- Analogue I/O
- High Level Instructions
- Special Modules ie High speed counters etc
- Control Registers
- Practical Exercises on Plant
- Simulation Systems
Advanced: Course Description
The following areas are designed to allow personnel to quickly determine the locations of faults on a PLC controlled plant, to develop their own programmes, and to monitor and fault find plant operation on both stand alone and networked systems.
The Programmable Logic Controllers Advanced course is designed for candidates who have specific objectives in mind.
- Local Area Networks
- Remote I/O Racks
- Interconnection with Scada
- Advanced Programming Instructions
- Communications Protocols
- Remote Monitoring & Control via modem etc
- Shift Register & Sequencer
- Register Read Write Commands
- Analogue I/O
- Error Codes, diagnosis
- Device Time Scans
- Network Interface Modules
- Alarm & Error Messages & Checking
- Interrupt & Fault Handling Routines
- Message & PID Control & Handling.
BOOK YOUR COURSE BELOW
£875.00 + VAT (£1,050.00 inc VAT & all fees)
Now comes with our brand new, extra accreditation at no extra cost! On Certification Course Only.
City & Guilds – Programmable Logic Controllers – UK’s first City & Guilds total accreditation!
What is Obtained/Achieved?
- Level 3 EAL award in Programmable Logic Controllers
- City & Guilds – Programmable Logic Controllers
05Mar4 hours, 08:30 AM - 12:30 PMEvent is fullSold out
15MarEvent is fullSold out
